Other grades of this product :
| 1,4,7,10-TETRAAZACYCLODODECANE TETRAHYDROCHLORIDE Basic information |
| Product Name: | 1,4,7,10-TETRAAZACYCLODODECANE TETRAHYDROCHLORIDE | | Synonyms: | CYCLEN-4HCL;CYCLEN TETRAHYDROCHLORIDE;1,4,7,10-Tetraazacyclododecane tetrahydrochloride, 97+%;1,4,7,10-Tetraazacyclododecane (Cyclen) tetrahydrochloride;Cyclen tetrahydrochloride,98%;1,4,7,10-Tetraazacyclododecane,hydrochloride;1,4,7,10-Tetraazacyclododecane, hydrochloride(1:4);1,4,7,10-TETRAAZACYCLODODECANE TETRAHYDROCHLORIDE | | CAS: | 10045-25-7 | | MF: | C8H21ClN4 | | MW: | 208.73 | | EINECS: | | Product Categories: | Analytical Chemistry;Azacrown Ethers;Crown Ethers;Functional Materials;Ligands for Pharmaceutical Research;Macrocycles for Host-Guest Chemistry;Magnetic Resonance Imaging (Chelating Reagents);Ring Systems | | Mol File: | 10045-25-7.mol |
| 1,4,7,10-TETRAAZACYCLODODECANE TETRAHYDROCHLORIDE Chemical Properties |
| Melting point | 297-300 °C | | storage temp. | Inert atmosphere,Room Temperature | | form | Crystalline Solid | | color | White | | Sensitive | Hygroscopic | | CAS DataBase Reference | 10045-25-7(CAS DataBase Reference) |
| Hazard Codes | Xi | | Risk Statements | 36/37/38 | | Safety Statements | 26-36 | | WGK Germany | 3 | | RTECS | XA5253000 | | F | 10-21 | | HazardClass | IRRITANT, MOISTURE SENSITIVE | | HazardClass | 9 | | HS Code | 29339900 |
| 1,4,7,10-TETRAAZACYCLODODECANE TETRAHYDROCHLORIDE Usage And Synthesis |
| Chemical Properties | white crystalline solid | | Uses | Cyclen tetrahydrochloride may be used for the synthesis of 1,4,7,10-tetraazacyclododecane-1,4,7,10-tetrakis(methyleneethylphosphinic acid), a new macrocyclic polyaza polyphosphinate ligand. It may also be used in the synthesis of anthraquinone-pendant cyclen. | | General Description | Cyclen tetrahydrochloride is a macrocycle hydrochloride salt. It can be synthesized using perhydro-2a,4a,6a,8a-tetraazacyclopenteno[1,3-f,g]acenaphthylene as a precursor. Cyclen tetrahydrochloride has an orthorhombic crystal structure. Cations are reported to exhibit crystallographic two-fold rotation symmetry and [3333] quadrangular conformation, having protonated N atoms at corner positions. Synthesis of cyclen from the corresponding butanedione-protected linear tetramines has been reported. |
| 1,4,7,10-TETRAAZACYCLODODECANE TETRAHYDROCHLORIDE Preparation Products And Raw materials |
|
