characteristics:
It takes modified alumina as supporter, carrying molybdenum, nickel, cobalt components and has the property of deep HDN,HDS and alkene saturation. The catalyst has outstanding compression resistance and abrasive resistance, can be regenerated by nitrogen -air or water vapor-air.
Application: It is widely used to hydrotreat light straight distilled oil and secondary processed gasoline for raw material of platiform..
Physical-chemical properties:
| item | target | item | target |
appearance | Trilope wxtrudates | Pore volume ,mL/g | min0.40 |
Particle size,mm | Ф(1.5-2.5)*(2-10) | NiO, wt% | 4.0-5.5 |
Crushing strength,N/cm | min150 | MoO3,wt% | 15.0-17.0 |
Bulk density,kg/L | 0.68-0.75 | CoO,wt% ≥ | 0.03 |
Suface area,m2/g | 200 |
|
|
Activity index:
| Process parameters | Hydrogen partial pressure, Mpa | temperature,℃ | Space cvelocity,hr-1 | Hydrogen to oil raatio,V/V |
3.0 | 320 | 1.5 | 500 | |
Raw material | Daqing coked gasoline | |||
Processed oil | Alkaline nitrides max0.5mg/l | |||
Reference operating conditions:
Process parameter Kinds of raw material |
Hydrogen partial pressure | Inlet reaction temperature(℃) |
Space velocity | Hydrogen to oil ratio(V/V) |
Platiforming material | 1.5-2.5 | 270-300 | 2.0-4.0 | 100-200 |
Secondary processed oil | 1.5-3.0 | 220-240 | 1.5-3.0 | 400-500 |
kerosene | 1.5-4.5 | 260-290 | 1.2-2.0 | 400-500 |
FCC diesel | 2.5-4.5 | 270-320 | 1.0-2.0 | 400-500 |
Packing: iron drums innerlining double-layer plastic bags.
